Manual Wheelchairs / QUICKIE / Folding Ultra Lightweight Wheelchairs / Quickie® QS5 X

QS5 X Folding Wheelchair

Experience FreeFold and save over 40% energy with every fold!

Find Your Dealer

Experience FreeFold and save over 40% energy with every fold!

Introducing the QUICKIE QS5 X, the wheelchair that redefines easy folding thanks to FreeFold - an innovative cross-brace design that reduces folding forces and saves you over 40% energy with every fold! The QS5 X makes light work of lifting, with an (optional) folding fastener that keeps the wheelchair tightly locked to prevent any unintentional opening during transport.

With a usable transport weight of just 16 lbs*, it's the lightest aluminum box frame wheelchair. Lock the heat-treated 7000-series aluminum frame in place, and its oval-tubed 4-arm cross-brace provides the ride performance to rival any rigid wheelchair. The QS5 X saves not only your energy, but your shoulders, too.

*Chair weight is calculated based on a 16"x16" seat dimension with back upholstery, side guards, and wheel locks. Transport weight is calculated with items that can be easily removed (i.e., swing-away footrests, armrests, rear wheels, and seating products).

Find Your Local Dealer

Available colors:

The color options shown are for reference only. They are not intended as accurate representations.

Options and Prices

3D Visualizer

Unleash your individuality and create your own QS5 X!

From push handles to caster forks, our online QUICKIE QS5 X visualizer will help you to create the QS5 X of your dreams! Style your ride with 24 vibrant frame colors, 4 caster fork colors, and 4 wheel colors. You can even match your cross-brace color to your frame! Just click the button below to begin.

START

Unleash your individuality and create your own QS5 X!

Folding performance

FreeFold - Over 40% energy saved with every fold.

The QS5 X is easy to fold, and it stays folded - thanks to the innovative FreeFold feature. FreeFold stands for sophisticated and precise engineering of the folding geometry, resulting in particularly little force needed to fold and unfold. During folding, the wheel camber does not change and the folded wheelchair stands solidly on the ground - a real benefit if you are frequently folding and transporting your chair.

More features

Lightweight

Easy propelling and lifting with the lightweight QS5 X.

A remarkably low usable transport weight* from 16 lbs. for the Fixed Front frame and 16.5 lbs. for the Swing-Away frame! As the lightest aluminum folding box frame on the market, the QS5 X is not only comfortable to lift and transport, but also effortless to self-propel. The material and construction make all the difference – strong doesn't always have to mean heavy. The frame of the QS5 X is made of high-grade 7000-series aluminum, designed for an exceptionally high strength-to-weight ratio and is used in many aerospace applications where strength, durability, and weight are essential factors.

More features

Easy propelling and lifting with the lightweight QS5 X.

Frame Versions: Fixed-Front or Swing-Away

The QS5 X is available with two different frame versions: Fixed-Front and Swing-Away.

The Fixed-Front* version has footrests that are permanently attached to the chair frame, providing additional stability and support. This feature can be particularly beneficial for people with higher positioning demands, as it helps to keep the legs in an ideal position.

The Swing-Away version has footrests that can be swung away to the side, which enables a safe and comfortable transfer into the chair, especially from a standing position. By removing the footrest, it's possible to position the wheelchair closer to the object you want to transfer on. Furthermore, the pack-size of the wheelchair will be minimized.

* Fixed-Front frame will be available to order soon.

Smart options

Bright, removable LED lights.

In many situations, it's good to have your own light - if you need to go to the bathroom at night and don't want to illuminate the whole house, or if you're on your way home in the evening and need to see obstacles that could throw you off balance. The QS5 X's LED lights are a great solution! Discreetly integrated into the overall design of the QS5 X and removable for charging, the LED lights provide a great feature to light your way when you need them!

More options

Specifications

Dimensions

Seat Width:13" to 20"

Seat Depth:13" to 20"

Front Seat-to-Floor Height:14" to 22"

Rear Seat-to-Floor Height:14" to 20"

Back Height:10" to 20"

Back Angle Adjustment:From 80° to 105°

Frame Angle:

Swing-Away: 70/80/90°
Fixed-Front: 75/85° and 1" inset

Center of Gravity (COG) Adjustment:1" to 3"

Product Information

HCPCS Code:K0005 / E1236

Performance/Weights

Frame Material:7000 Aluminum

Transit:Yes; conforms to ISO 7176-19 Transit Approved standards

User Weight Capacity:300 lbs.

Product Weight:

Swing-Away: from 22.3 lbs.
Swing-Away (usable transport*): from 16.5 lbs.
Fixed-Front: from 21.8 lbs.
Fixed-Front (usable transport*): from 16.1 lbs.

As a part of our ongoing product improvement initiative, Sunrise Medical reserves the right to change specifications and design without notice. Further, not all features and options offered are compatible with all configurations of the wheelchair. Please consult the user instruction manual for more information.

Support

Documentation

Brochures

Quickie QS5 X Brochure

Order Forms

Quickie® QS5 X Order Form (Nov 2024)

Owners Manuals

Quickie QS5 X Owner's Manual

Other

Quickie QS5 X Poster

Frequently Asked Questions

Can the backrest height be adjusted?

Yes, by raising and lowering the push handles in the rear side frame or back frame one can adjust the back height.

Where can I find the serial number on my wheelchair?

Your serial number is usually found on the frame underneath the seat (or on the cross brace of a folding wheelchair). It will be a white sticker with a barcode and a series of numbers.

I've scratched the frame of my wheelchair. Do you offer touch-up paint?

Unfortunately we don't. However, nail varnish is an extremely inexpensive and easy way of fixing any small scratches or blemishes to your wheelchair's frame.

What wheelchair cushions are available?

There are a number of different wheelchair cushions available for our products. You can view our complete range of JAY wheelchair cushions online. For the best comfort we advise you to contact your nearest authorized Sunrise Medical dealership.

Can I get my wheelchair in different colors?

Yes you can! You can find the list of available colors on the product's order form. If you're looking for something more unique, our Built-4-Me team can help supply a product to your specific needs.
